Turning and Milling Compound Machining Center
✔ Workpiece dia., max.: 150 mm
✔ Workpiece length, max.: 200 mm
Description
Technical Parameters
The DASK CNC C Series milling and turning machines integrate turning, milling, drilling, tapping, and other multi-process functions, enabling complete machining of complex parts in a single clamping. This series is particularly well-suited for the mass production of high-precision, small-diameter parts and is widely used in automotive components, electronics, medical devices, precision engineering , and other fields.
Core Highlights
Multifunctional integration :
Turning, milling, drilling and tapping are completed in one operation, reducing process and clamping errors.
High-precision structure :
Spindle runout ≤ 0.003 mm, repeat positioning accuracy 0.003 mm, ensuring part consistency.
Electric spindle drive :
speed range 5–3500 r/min, rated speed 2500 r/min, taking into account both strong torque and high speed requirements.
Efficient feed :
X/Z axis travel is 230/680 mm respectively, and rapid traverse speed is 20–30 m/min, ensuring flexible and efficient processing.
Intelligent measurement :
The grating has an absolute measurement resolution of 0.001 mm, ensuring micron-level precision control.
Compact design :
Small footprint, suitable for flexible production and automated line layout in workshops.
Technical Parameters
|
project |
Specification |
unit |
|
Processing capabilities |
||
|
Maximum swing diameter |
Ø350 |
mm |
|
Maximum workpiece diameter |
Ø150 |
mm |
|
Maximum workpiece length |
200 |
mm |
|
spindle |
||
|
Spindle speed range |
5 – 3500 |
r/min |
|
Rated speed of main motor |
2500 |
r/min |
|
Spindle drive mode |
Electric spindle |
- |
|
X/Z axis |
||
|
journey |
230 / 680 |
mm |
|
Fast movement |
20 – 30 |
m/min |
|
Accuracy |
||
|
Spindle runout |
≤0.003 |
mm |
|
Grating measurement resolution |
0.001 |
mm |
|
Repeat positioning accuracy |
0.003 |
mm |
Application Scenarios
Automotive industry : precision shafts, transmission components, small flange parts
Electronics and medical : high-precision connector housings, medical implants
Mechanical manufacturing : small gears, bushings, bearing parts
Mold industry : mold inserts, small parts with complex structures
Customer Value
Reduce costs and increase efficiency :
Complete complex processes with one clamping, reducing manual handling and multi-machine processing costs.
High quality assurance :
Micron-level repeat positioning and spindle runout control ensure part batch accuracy.
Flexible production :
Suitable for multi-variety and small batch production, able to quickly respond to customer needs.
Automation support :
Scalable power tools, manipulators, and online measurement to achieve unmanned production.
Optional Configuration
- Power tool function
- Automatic loading and unloading robot
- High-pressure cooling system
- Online detection and compensation system
- Multi-language CNC system (FANUC / Siemens / domestic high-end CNC system)
